Connect 2 wires of Key if you need the module to work recurently after power on. (T2) delay on this cycle, T1 and T2 setting by two adjustable resistors, respectively; when triggered on the delay process, again triggered, it will immediately interrupt the delay. This tiny but mighty timer relay handles delays from 0.1 to 120 seconds with four modes: power-on delay, auto-off, self-locking, or level trigger. Works at 5V, 12V, or 24V DC (pick your version Load capacity: 10A (AC0-250V, DC0-30V). Features: Type: DC5 V, 0-30 minutes/DC5 V, 0-24 hours/DC12 V, 0-120 mins/DC12 V, 0-24 hours/DC24 V, 0-30 minutes (optional). Dc 5v/ 12v/ 24v Trigger Infinite Cycle Delay Timer Relay Switch Turn On VK4PK - JK11 Adjustable Cycle Timer Delay Time accuracy: maximum value x 0., 001., Package includes: 1 x Delay Relay Module [Can change mode]: you can simply change the mode by adjusting the jumper. You can set the time to turn on and off. Adjustable Cycle Timer FCMY DC 5V 12V 24V Delay Relay Module Delay On Timer Relay Module [Performance and functions]: This is a delay relay module offering stable, reliable and high precision performance, widely used on timer operating equipment, repetitive test circuit, intermittent pump of aquariums, etc.
