When there is a pair of monitoring interfaces working, it is forbidden to connect to the equipment onother monitoring interfaces. Supports multiple charging protocols including PD2.0, PD3.0, QC2.0, and QC3.0, making it ideal for various devices and fast charging technologies After using the PD trigger/monitor/conversion/read E-Marker cablefunction, please turn the PD communication switch in the lower rightcorner back to the OFF position. (Except the PC connection port, the PC port can be connected to an external power supply). 【Fast Charge Protocol Trigger Detection】FNB58 supports trigger detection of various fast charging protocols, QC2., 0/QC3., 0 trigger, FCP/SCP trigger, AFC trigger, PD2., 0/3., 0 trigger, VOOC/WARP trigger, Super VOOC 1., 0/2., 0 trigger. FNIRSI FNB48P USB Voltage Current Tester with Bluetooth Only one pair of monitoring interfaces (one input port,one outputport) can work at the same time. 10 sets of switchable capacity, power and time statistics. Ripple Measurement Tool FNIRSI USB Tester 4-28V 7A LCD USB A&C Voltage Current Power Tester Multimeter USB A Tester 【Updated Designed USB Tester】FNIRSI FNB58 USB tester has a 2., 0-inch full-color ultra-wide viewing angle TFT LCD display, integrated USB-A, Micro-USB, Type-C interface. FNIRSI-C1 USB Tester Type-C PD Trigger - FNIRSI Oscilloscope Official Support low-speed waveform (voltage, current, D+/D-) drawing, 2sps->100sps sampling rate. The internal resistance measurement of the wire by the differential pressure method. It can be used to measure the power supply or power consumption of products such as USB interfaces, mobile phone chargers, and U disks. Do not charge the phone after the fast charge is triggered. Support high-speed ripple (voltage, AC coupling)drawing, up to 4M sps sampling rate. 【Parameter Detection and Recording】The highest six-digit display of voltage, current and power, the highest resolution is 0., 00001 (V/A/W). It can be used to test the fast charging protocol of chargers. FNB58 USB tester is a high-reliability, high-safety USB voltage andcurrent detection meter and a mobile communication terminal fast chargingtrigger., It has a 2., 0-inch full-color ultra-wide viewing angle TFT LCD display, integrated USB-A, Micro-USB, Type-C interface. It can be used to measure the charging power of mobile phones and the input and output of mobile power supplies. Record of startup time., Onboard temperature measurement., PD monitor., Analog DASH cable. 【Multifunction USB Digital Tester】FNB58 uses external 16-bit ADC, PD protocol physical chip. FNB58 USB tester can monitor the voltage, current, power, resistance, capacity, temperature, D+/D- voltage etc, it can be used to test the fast charging protocol of chargers. ☆☆In order to respond to the environmental protection policy and reduce the waste and use of paper, FNB58 does not come with paper manuals.
