PGN #50 Roller Chain Offset Links - 5/8" Pitch - Half Link (5 Pack

Chain Half Link 5 Pack PGN #50 Roller Chain Offset Links - 5/8" Pitch - Half Link (5 Pack 5/8 Pitch Offset Link MAXCO Hi-Max® 50NP Nickel Plate Offset Link Cotter Pin Type ASME/ANSI 50-2 Roller Chain Offset Links - Summit Collars & Industrial Supply About this item ANSI Chain No.: #50 Units per package: 5 Single Strand Pitch (P): 0.62 inches Carbon Steel Report an issue with this product Units per package: 5 Below are the specifications for the chain that uses this half link: ANSI Chain No., : #50 Pitch (P): 0., 625 inch (15., 875 mm) Roller Diameter (d1 max): 0., 4 inch (10., 16 mm) Width Between Inner Plates (b1 min): 0., 370 inch (9., 4 mm) Pin Diameter (d2 max): 0., 2 inch (5., 08 mm) Pin Lenght (L max): 0., 815 inch (20., 70 mm) Pin Lenght (Lc max): 0., 874 inch (22., 20 mm) Inner Plate Depth (h2 max): 0., 594 inch (15., 09 mm) Plate Thickness (T max): 0., 080 inch (2., 03 mm) Ultimate Tensile Strenght (Q min): 22., 20/5045 kN/LB Average Tensile Strenght (Qo): 29., 4 kN Weight (q): 0., 685 lb/ft (1., 02 kg/m), ANSI Chain No., : #50 , Units per package: 5 , Single Strand , Pitch (P): 0., 62 inches , Carbon Steel
