This Kerick PS150SS float valve is a standard-mount style and is made of PVC with 18-8 stainless steel hardware. This heavy-duty, non-corrosive, PVC float valve is a standard mount unit with a 1.0" orifice. For use with a 5/16" threaded stainless steel rod The valve inlet and outlet have 1-1/2 NPT male threads for attaching to NPT female fittings. For use with 12-18 x 5/16 stainless steel rod and 8 float ball (sold separately) The valve is made of National Sanitation Foundation (NSF) approved PVC (polyvinyl chloride), its replaceable seals are made of TPE (thermoplastic elastomer) for durability and chemical resistance, and its hardware is made of 18-8 stainless steel for corrosion resistance. Float valves are rated according to the volume of liquid that can flow through them at a particular pressure to ensure the tank can be refilled as quickly as it is emptied. The valve uses a 14, 16, or 18 x 5/16 stainless steel rod and a 6 or 8 float ball (sold separately). This float valve is suitable for use in a variety of applications, such as fountains, livestock water tanks, and chemical manufacturing plants. Dual ranges for estimated rate of flow up to 124 gpm at 50 psi (low flow) and 145 gpm at 50 psi (high flow) The valve has lever brackets on both the top and bottom of the valve with a different fulcrum position for each bracket, which allows a low and high flow rate at a particular pressure., This valve has a 1., 0 orifice with a low estimated rate of flow of 85 gallons per minute (gpm) at 20 pounds per square inch (psi) and 124 gpm at 50 psi and a high estimated rate of flow of 90 gpm at 20 psi and 145 gpm at 50 psi. Standard Mount Float Valve For Water Tank Kerick - Kerick Float Valves - Float Valves By Gadren Machine Industrial Water Level Control When the angle of the valve lever changes sufficiently, the valve opens or closes. Float Valve 1-1/2 Inch Pvc Pipe Mount | AD7CYU | 4DME5 | Worldwide Delivery | sales@ | 44 203 287 5224 Float valves are used to automatically regulate the level of liquid within tanks in a variety of applications, such as fountains, livestock water tanks, cooling towers, and chemical manufacturing plants. SINGLE ACTING HYDRAULIC TIPPER VALVE, DUAL PRESSURE, 2000 PSI MAIN 1-1/2 NPT male threaded inlet and outlet
