STEPPERONLINE Nema 23 Geared Stepper Motor 2.8A L=56mm Gear Ratio

4-wires (Black, Green, Blue, Red) , Weight: 1., 5kg Dieser Nema 23 Schrittmotor mit 55mm Gehäuselänge und 2,8A Nennstrom, integriert mit einem 61,65mm Planetengetriebe von 15: 1 Getriebe übersetzung Permissible Torque: 30Nm(4248oz-in) * Moment Permissible Torque: 50Nm(7080oz-in) * Shaft Maximum Axial Load: 100N * Shaft Maximum Radial Load : 200N Physical Specifications * Frame Size: 60 x 60mm * Motor Length: 56mm * Gearbox Length: 60mm * Shaft Diameter: Φ12mm * Shaft Length: 30mm * Key-way length: 20mm * Key-way width : 4mm * Number of Leads: 4 * Lead Length: 500mm * Weight : 1., 5kg Connection: Black(A+), Green(A-), Red(B+), Blue(B-) Warning: Make sure the motor connect to a constant current or chopper drive controller before you test motor. Misumi High Precision Compact Type / 42mm Stepper Motor 3D Printe Nema 17 Stepper Motor CNC Robotics Stepper Motor STEPPERONLINE Nema 23 Geared Stepper Motor 2.8A L=56mm Gear Ratio High Torque Stepper Frame Size: 60 x 60 mm / 2., 36 x 2., 36 , Motor Length: 56 mm / 2., 20 , Gearbox Length :60 mm / 2., 36 This Nema 23 stepper motor with 56mm body and 2.8A rated current, integrated a planetary gearbox of 15.3:1 gear ratio. It's a good solution to applications that with limited space but need low speed and/or high torque Bipolar Stepper, Holding Torque: 15., 5Nm , Rated Current/phase : 2., 8A , Gearbox Type: Planetary Connecting the motor directly to a power supply will destroy the motor.
