DATAKOM AVR-40 Automatic voltage regulator for generator alternators. Buy online ATS, AMF, AVR, ECM, DKG controllers for diesel, gas, petrol gensets including manual start units and auto mains failure generator controls, electronic Its single phase sensing comes as standard. Precision of voltage regulation: ± 1% from no-load to nominal load in static condition, with any power factor and for frequency variations ranging from -5% to 20% of the nominal value This allows changes to the AVR settings, to monitor in real-time performances (Voltage, Frequency or DSR status), or to download the alarm report Features Analogical remote control of output voltage is possible through external voltage (0-2,5Vdc) or with a 10 Kohm linear potentiometer Underspeed protection with adjustable threshold and slope Overvoltage and undervoltage alarms Excitation overcurrent protection with delayed intervention Management of temporary short circuits (start up of asynchronous motors) Open collector output (not insulated) signalling intervention of protective devices (insulation on optional DI1 module) with programmable activation with respect to the individual alarms and the possibility to delay intervention Abnormal operation conditions storage (type of alarm, number of events, duration of the last event, total time) Memorization of the regulator operation time (starting from revision 11 of the Firmware) ., ., ., The AVR DSR is an advanced AVR replacing the traditional automatic voltage regulator Free Shipping Fast Delivery Mecc Alte DSR AVR Generator Automatic Voltage Regulator T3ll I.1661898268 Analogical remote control of output voltage is possible through external voltage (0-2,5Vdc) or with a 10 Kohm linear potentiometer This voltage regulator is fully digital controlled and is fitted as standard across all our ECO and ECP models Reliable DSR AVR automatic voltage regulator ensures stable power output for your generator genset operation. Maintains consistent voltage for generator genset performance This voltage regulator is fully digital controlled and is fitted as standard across all our ECO and ECP models Connections on the DSR are through 15 fast on / fast off connectors which speed up the connection process. This regulator is cross-compatible with all ECO and ECP machines and can be used as standard with the MAUX system and the PMG ma systems, so there’s never any need to change regulators. This is especially useful if reconnecting a 12 wire machine to any specific voltage.
